General characteristics

HAM bands
2m  70cm
Frequency stability
?
Tuning steps
5 / 10 / 12.5 / 15 / 20 / 25 kHz
Memories
800 channels in 1 bank(s)

Receiver

RX-range
144-146 / 430-440 MHz (Europe)
144-148 / 430-450 MHz (USA)
Modulations
FM
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
?

Transmitter

TX-range
144-146 / 430-440 MHz (Europe)
144-148 / 430-450 MHz (USA)
Modulations
FM
RF-output
High: 50/35 W, Low: 5/5 W

Connections

Antenna
-
Impedance
50 Ω
Other
-

Electrical

Power requirements
13.8V DC
Current drain RX
Max 0.6 A
TX
Max 11.5 A

Physical

Dimensions (w×h×d)
140 × 40 × 155 mm (5.51 × 1.57 × 6.10 in)
Weight
1,000 gr (2.2 lbs)
Form factor
Mobile
Manufactured
Between 199x and 199x

Other features

Usage
Amateur / Ham radio operators
Features + options
Twin RX
Accessories
-
RigReference ID
4306
MPN
YAESU-FT-005200
