Uniden-Bearcat BC346XT

Handheld VHF/UHF Scanner / receiver

Specs Manuals (0) Reviews (0) Prices (0) Compare

Find Uniden-Bearcat BC346XT rigs and spare parts on eBay

Find the Uniden-Bearcat BC346XT on Amazon
We receive a small fee if you buy through these links, which helps support this site. Thank you!

The Bearcat BC-346XT features third generation TrunkTracking III technology supporting Motorola Systems Type I, II, II/I (hybrid), EDACS Systems FM, NFM, and SCAT plus LTR Systems. The BC346T has many innovative features including Uniden’s exclusive Close Call™ RF Capture Technology and there is EDACS ESK support. The BC346XT uses a dynamically allocated memory system, allowing the user to program up to 9000 channels. While traditional scanners have been limited to only ten banks, the BC346XT groups channels into systems, allowing for up to 500 systems to be programmed and scanned simultaneously. Systems can still be quickly enabled or disabled using the 0-9 keys, and each system can have up to 10 groups of channels that are also available for quick selection. Uniden’s exclusive Close Call™ RF Capture Technology zeroes in on nearby transmissions without the need for programming, even when the BC346XT is in other modes, scanning, searching or holding on a frequency. For example, if someone transmits within a few hundred feet (range depends on transmit power and other radio traffic in the area), the scanner immediately detects and tunes to the transmission, ideal for use at events when the frequency being used is unknown. And frequency coverage is great. You get VHF low, VHF High, VHF Air, UHF, 800 MHz Public Service (less cellular) and even the 1.24-1.3 GHz amateur radio ham band.

General characteristics

HAM bands: 11m (CB) 6m 2m 1.25m 70cm 33cm 23cm 10m 4m
Frequency stability: ?
Tuning steps: 5 to 100 kHz
Memories: 9000 channels in 500 bank(s) @ 100 channels/second

Receiver

RX-range: 25-225 / 400-512 / 806-824 / 850-869 / 895-960 / 1240-1300 MHz
Modulations: AM FM N-FM W-FM
Sensitivity: 0.4μV 25–27.995 MHz AM
0.3μV 28–53.98 MHz N-FM
0.5μV 54–71.95 MHz W-FM
0.2μV 72–75.995 MHz FM
0.4μV 76–107.9 MHz FM-B
0.3μV 108–136.9916 MHz AM
0.3μV 137–173.9875 MHz N-FM
0.5μV 174–215.95 MHz W-FM
0.3μV 216–224.98 MHz N-FM
0.3μV 400–512 MHz N-FM
0.4μV 806–960 MHz N-FM
0.5μV 1240–1300 MHz N-FM
Selectivity: ?
Filters: ?
Receiver system: Triple conversion superheterodyne
IF-frequencies: 1st: 380.7 to 380.8 MHz
2nd: 10.8 MHz
3rd: 450 kHz
Image rejection: ?
Audio output: 320 mW, 8 ohm

Connections

Antenna: SMA
Impedance: 50Ω
Other: -

Electrical

Power requirements: 3V DC (3×AA), 12V DC external
Current drain RX: 500 mA
TX: -

Physical

Dimensions (w×h×d): 61 × 136 × 31 mm (2.40 × 5.35 × 1.22 in)
Weight: 168 gr (5.9 oz)
Form factor: Handheld
Manufactured: Between 2004 and 20xx

Other features

Usage: Amateur / Ham radio operators
Features + options: CTCSS / DCS
GPS connectivity
PC programmable
Trunktracker III, tracks Motorola Systems: Type I, II, II/I (hybrid), EDACS Systems (FM, NFM, and SCAT), LTR Systems
Turbo-search (300 chn/sec)
Accessories: -
RigReference ID: 4473
MPN: UNIDEN-BEARCAT-BC000346XT
