When a GPS-unit is connected, it
can also alert at areas of special interest, such as dangerous intersections, school zones or general points of interest.

General characteristics

HAM bands
?
Frequency stability
?
Tuning steps
5 / 10 / 12.5 / 20 / 25 / 50 / 100 kHz
Memories
2500 channels in 1 bank(s) @ 100 channels/second

Receiver

RX-range
25-512 / 758-824 / 850-869 / 894-960 / 1240-1300 MHz
Cellular blocked
Modulations
AM   FM   W-FM   APCO-25
Sensitivity
25-28 MHz AM: 0.3 µV
28-54 MHz NFM: 0.3 µV
54-72 MHz WFM: 0.5 µV
72-76 MHz FM: 0.2 µV
76-108 MHz WFM: 0.5 µV
108-137 MHz AM: 0.3 µV
137-174 MHz NFM: 0.2 µV
174-216 MHz WFM: 0.5 µV
216-225 MHz NFM: 0.3 µV
225-378 MHz AM: 0.3 µV
380-512 MHz NFM: 0.3 µV
758-960 MHz NFM: 0.3 µV
1240-1300 MHz NFM: 0.4 µV
Selectivity
?
Filters
?
Receiver system
Triple conversion superheterodyne
IF-frequencies
1st: 380/265 MHz
2nd: 10.8 MHz
3rd: 450 kHz
Image rejection
?
Audio output
3 watts nominal (@ 10% THD)

Connections

Antenna
BNC
Impedance
50Ω
Other
-

Electrical

Power requirements
11-16.6V DC
Current drain RX
?
TX
-

Physical

Dimensions (w×h×d)
183 × 56 × 150 mm (7.20 × 2.20 × 5.91 in)
Weight
1.55 kg (3.4 lbs)
Form factor
Mobile
Manufactured
Between 2009 and 201x

Other features

Usage
Amateur / Ham radio operators
Features + options
CTCSS/DCS
"Close Call" RF capture technology
Trunktracker IV, tracks Motorola I, II & IIi, EDACS and LTR
Band scope
Multi-color display backlight
NAC-decoding
Individual channel volume offset
RS-232C
GPS-enabled for location-related scanning
Turbo-Search (300 chn/sec)
Accessories
-
RigReference ID
4520
MPN
UNIDEN-BEARCAT-BCD000996XT

Manuals, diagrams and brochures

Uniden BCD996T Programming Control Codes PDF - Unknown size, submitted by RigReference

Upload relevant documents

Reviews & stories

Rating Title Submitted
Love this scanner! 10 years ago by KE4RWS

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Uniden-Bearcat BCD996XT. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the Uniden-Bearcat BCD996XT is around:

  • USD 77.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2010 USD 482.95 New / Good universal-radio
