When a GPS-unit is connected, it can also alert at areas of special interest, such as dangerous intersections, school zones or general points of interest.

General characteristics

HAM bands
?
Frequency stability
?
Tuning steps
?
Memories
9000 channels in 1 bank(s)

Receiver

RX-range
25-512 / 758-824 / 849-869 / 894-956 / 1240-1300 MHz (less cellular in the US)
Modulations
AM   FM   W-FM
Sensitivity
25-28 MHz AM: 0.4 µV
28-54 MHz FM: 0.3 µV
54-72 MHz WFM: 0.6 µV
72-76 MHz FM: 0.2 µV
76-108 MHz WFM: 0.5 µV
108-137 MHz AM: 0.3 µV
137-174 MHz FM: 0.3 µV
174-216 MHz WFM: 0.5 µV
216-225 MHz FM: 0.3 µV
225-380 MHz AM: 0.3 µV
380-512 MHz FM: 0.3 µV
758-960 MHz FM: 0.3 µV
1240-1300 MHz FM: 0.4 µV
Selectivity
?
Filters
?
Receiver system
Triple conversion superheterodyne
IF-frequencies
1st: 380/265 MHz
2nd: 10.7 MHz
3rd: 450 kHz
Image rejection
?
Audio output
?

Connections

Antenna
BNC
Impedance
50 Ω
Other
-

Electrical

Power requirements
11-16.6V DC
Current drain RX
500 mA max
TX
-

Physical

Dimensions (w×h×d)
184 × 56 × 155 mm (7.24 × 2.20 × 6.10 in)
Weight
1.55 kg (3.4 lbs)
Form factor
Mobile
Manufactured
Between 2009 and 201x

Other features

Usage
Amateur / Ham radio operators
Features + options
Beartracker warning system
"Close call" RF capture technology
RS-232C
Tracks Motorola type I, II. EDACS, SCAT and LTR systems.
CTCSS/DCS
Repeater reverse
S.A.M.E Weather alert
FIPS code
GPS-enabled for location-related scanning
Band scope
Individual channel volume offset
Accessories
-
RigReference ID
4521
MPN
UNIDEN-BEARCAT-BCT000015X

Manuals, diagrams and brochures

Uniden BCT15 Programming Control Codes PDF - Unknown size, submitted by RigReference

Upload relevant documents

Reviews & stories

Rating Title Submitted
BCT15X 4 years ago by k0mixham@gmail.com

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Uniden-Bearcat BCT15X. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the Uniden-Bearcat BCT15X is around:

  • USD 83.00 ~ USD 139.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2015 USD 155.00 New / Mint k0mixham@gmail.com
2015 USD 155.00 New / Good k0mixham@gmail.com
2010 USD 208.95 New / Good universal-radio
