WiNRADiO WR-G33EM

Headless HF/VHF/UHF Scanner / receiver

Add a review Add to my shack


Login or Register to upload images

DSC, NAVTEX, HF FAX, TELEX marine modes.
USB (1.1 / 2.0) compatible computer connection.

General characteristics

HAM bands
?
Frequency stability
10 ppm (0 to 60 C)
Tuning steps
1 Hz kHz

Receiver

RX-range
9 kHz - 30 MHz
Modulations
AM   N-AM   CW   USB   LSB   DSB
Sensitivity
Mode 0.1-0.5 MHz 0.5-2.0 MHz 2.0-30 MHz
AM* 2.0µV 0.5µV 0.4µV
LSB, USB 0.7µV 0.3µV 0.2µV
CW 0.3µV 0.2µV 0.1µV

(10dB S+N/N)
* 80% modulation
Selectivity
Continuously adjustable 100-15000 Hz
Filters
?
Receiver system
DDS-based dual-conversion superheterodyne with software-defined last IF stage and demodulator
IF-frequencies
?
Image rejection
60 dB
Audio output
?

Connections

Antenna
SMA
Impedance
50Ω
Other
-

Electrical

Power requirements
12V DC
Current drain RX
500mA
TX
-

Physical

Manufactured
Between 200x and 200x
Dimensions (w×h×d)
164 × 96 × 41 mm (6.46 × 3.78 × 1.61 in)
Weight
467 gr (1.0 lbs)
Form factor
Headless

Other features

Memories
?
Usage
Marine / Navy
Features + options
DSP
Trunking option
12 kHz IF2 output
Number of memory channels limited by computer memory
Accessories
?
MPN
WINRADIO-WR-G000033EM
