WiNRADiO WR-1550e Headless HF/VHF/UHF Scanner / receiver

  Add a review   View all reviews (0)   Add to my shack




The WinRadio WR-1550e is a medium-range external receiver similar to its popular predecessor WR-1500e with improved dynamic range, spurious signal rejection and selectivity. The frequency range is 150 kHz to 1.5 GHz (the US version excludes cellular frequencies 825-849 and 869-894 MHz).

Frequency range

RX-range
0.15-1500 MHz
TX-range
-
HAM bands
-
Stability
10 ppm (0 to 60° C)
Tuning steps
1 Hz / 0.01 kHz
Filters
-

Find the WiNRADiO WR-1550e on ebay

Receiver

Modulations
AM   N-FM   W-FM   USB   LSB
Sensitivity
AM/SSB/CW: 10dB S/N
FM-N/FM-W: 12dB SINAD

Mode 0.15-1.5 MHz 1.5-30 MHz 30-1000 MHz 1-1.5 GHz
AM 25µV 1µV 1µV 1.9µV
SSB 0.9µV 0.3µV 0.3µV 0.4µV
FM N 0.4µV 0.4µV 0.4µV 0.4µV
FM W - - 1.0µV 1.0µV
Selectivity
SSB/CW 2.5 kHz @ 6dB
AM 6 kHz @ 6dB
FM-N 15 kHz @ 6dB
FM-W 230 kHz @ 6dB
Receiver system
-
IF-frequencies
-
Image rejection
65dB
Audio output
0.2W (8 ohm load)

Transmitter

Modulations
-
RF-Output
-

Connections

Antenna
BNC
Impedance
50 Ω

Electrical

Power requirements
-
Current drain RX
-
TX
-

Physical

Dimensions (w×h×d)
-
Weight
-
Form factor
Headless
Manufactured
Between 199x and 200x

Other features

Memories
-
Usage
Amateur / Ham radio operators
Features + options
RS-232 computer interface
Accessories
-
