RadioShack / Realistic Pro-160 Mobile HF/VHF/UHF Scanner / receiver

 (0.0/5)  Add a story   View all stories (0)   Add to my shack



Login or Register to upload images

Trunking: Motorola, Edacs and LTR. Made by Uniden.

Frequency range

RX-range
25-1300 MHz (except cellular)
TX-range
-
HAM bands
-
Stability
-
Tuning steps
-
Filters
-

Receiver

Modulations
AM   FM
Sensitivity
FM
28-54: 0.4μV
137-174: 0.4μV
216-224.995: 0.4μV
400-512: 0.4μV
764-775.9875: 0.5μV
794-823.9875: 0.5μV
849.0125-868.9875: 0.5μV
894.0125-956: 0.5μV
1240-1300: 0.8μV
AM (20 dB S/N at 60% modulation)
25-27.9950: 1.0μV
108-136.9875: 1.0μV
225-319.9875: 1.0μV
320-399.9875: .1.0μV
W-FM (20 dB S/N at 22.5 kHz deviation)
179.750–215.750 MHz: 0.8 μV
Selectivity
-
Receiver system
Triple conversion superheterodyne
IF-frequencies
1st: 265.55/380.75 MHz
2nd: 10.80 MHz
3rd: 450 kHz
Image rejection
75 dB (at 162.4 MHz)
Audio output
2 W

Transmitter

Modulations
-
RF-Output
-

Connections

Antenna
BNC
Impedance
50Ω

Electrical

Power requirements
12V DC
Current drain RX
470 mA max
TX
-

Physical

Dimensions (w×h×d)
187 × 56 × 152 mm (7.36 × 2.20 × 5.98 in)
Weight
1.50 kg (3.3 lbs)
Form factor
Mobile
Manufactured
Between 2008 and 20xx
MPN

Other features

Memories
1100 channels in 1 bank(s) @ 270 channels/second
Usage
Amateur / Ham radio operators
Features + options
-
Accessories
-

Manuals, diagrams and brochures

No documents available for this particular model.

Upload relevant documents

Show other documents.

Stories & reviews

Do you know this rig? Tell us something about it!

What is it worth?

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the current value of the RadioShack / Realistic Pro-160. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's value of the RadioShack / Realistic Pro-160 might be around:

  • USD 161.00
Price Condition Year User
USD 225.00 New / Mint 2012 KW9JGH
