RadioShack / Realistic Pro-160

Mobile HF/VHF/UHF Scanner / receiver

Add a review Add to my shack


Login or Register to upload images

Trunking: Motorola, Edacs and LTR. Made by Uniden.

General characteristics

HAM bands
?
Frequency stability
?
Tuning steps
?
Memories
1100 channels in 1 bank(s) @ 270 channels/second

Receiver

RX-range
25-1300 MHz (except cellular)
Modulations
AM   FM
Sensitivity
FM
28-54: 0.4μV
137-174: 0.4μV
216-224.995: 0.4μV
400-512: 0.4μV
764-775.9875: 0.5μV
794-823.9875: 0.5μV
849.0125-868.9875: 0.5μV
894.0125-956: 0.5μV
1240-1300: 0.8μV
AM (20 dB S/N at 60% modulation)
25-27.9950: 1.0μV
108-136.9875: 1.0μV
225-319.9875: 1.0μV
320-399.9875: .1.0μV
W-FM (20 dB S/N at 22.5 kHz deviation)
179.750–215.750 MHz: 0.8 μV
Selectivity
?
Filters
?
Receiver system
Triple conversion superheterodyne
IF-frequencies
1st: 265.55/380.75 MHz
2nd: 10.80 MHz
3rd: 450 kHz
Image rejection
75 dB (at 162.4 MHz)
Audio output
2 W

Connections

Antenna
BNC
Impedance
50Ω
Other
-

Electrical

Power requirements
12V DC
Current drain RX
470 mA max
TX
-

Physical

Dimensions (w×h×d)
187 × 56 × 152 mm (7.36 × 2.20 × 5.98 in)
Weight
1.50 kg (3.3 lbs)
Form factor
Mobile
Manufactured
Between 2008 and 20xx

Other features

Usage
Amateur / Ham radio operators
Features + options
-
Accessories
-
RigReference ID
4698
MPN
RADIOSHACK-/-REALISTIC-PRO-000160

Manuals, diagrams and brochures

No documents available for this particular model.

Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used RadioShack / Realistic Pro-160. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the RadioShack / Realistic Pro-160 is around:

  • USD 89.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2012 USD 225.00 New / Mint KW9JGH
