PCB by Cybernet Enterprise Japan

General characteristics

HAM bands
11m (CB)
Frequency stability
?
Tuning steps
Channelized
Memories
120 channels in 3 bank(s)

Receiver

RX-range
26.965-28.305 MHz
Modulations
AM   FM   USB   LSB
Sensitivity
AM: 0.7 µV @ 10 dB S/N
SSB: 0.2 µV @ 10 dB S/N
FM: 0.5 µV @ 20 dB S/N
Selectivity
AM: 6 kHz
SSB: 2 kHz
FM: 6 kHz
Filters
?
Receiver system
Single (SSB) / Double (AM/FM) conversion superheterodyne, PLL
IF-frequencies
1st: 10.695mhz
2nd: 455 kHz
Image rejection
60 dB
Audio output
3 W into 8 Ohms

Transmitter

TX-range
26.965-28.305 MHz
Modulations
AM   FM   USB   LSB
RF-output
AM/FM: 7.5 W, SSB: 12 W PEP

Connections

Antenna
SO-239
Impedance
50Ω
Other
-

Electrical

Power requirements
13.8 V DC
Current drain RX
?
TX
?

Physical

Dimensions (w×h×d)
190 × 60 × 250 mm (7.48 × 2.36 × 9.84 in)
Weight
2.00 kg (4.4 lbs)
Form factor
Mobile
Manufactured
Between 198x and 198x in Japan

Other features

Usage
Citizen Band (27Mc)
Features + options
-
Accessories
-
RigReference ID
4791
MPN
HY-GAIN-V-(002795)

Manuals, diagrams and brochures

Hy-Gain V Instruction Manual PDF - 2.79 MB, submitted by RigReference

Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Hy-Gain V (2795). Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the Hy-Gain V (2795) is around:

  • GBP 32.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2016 GBP 40.00 Used / Okay BandRunner
