General characteristics

HAM bands
11m (CB)
Frequency stability
± 0.03 %
Tuning steps
Channelized
Memories
80 channels in 1 bank(s)

Receiver

RX-range
26.965-27.855 MHz
Modulations
AM
Sensitivity
0.5 µV for 10 dB S+N/N
Selectivity
?
Filters
?
Receiver system
Double conversion superheterodyne
IF-frequencies
?
Image rejection
?
Audio output
?

Transmitter

TX-range
26.965-27.855 MHz
Modulations
AM
RF-output
8 W

Connections

Antenna
SO-239
Impedance
50Ω
Other
-

Electrical

Power requirements
13.8 V DC
Current drain RX
?
TX
?

Physical

Dimensions (w×h×d)
160 × 55 × 200 mm (6.30 × 2.17 × 7.87 in)
Weight
1.76 kg (3.9 lbs)
Form factor
Mobile
Manufactured
Between 198x and 198x in Taiwan

Other features

Usage
Citizen Band (27Mc)
Features + options
ANL
Accessories
-
RigReference ID
4901
MPN
PRESIDENT-PULSER-000800
