General characteristics

HAM bands
6m
Frequency stability
?
Tuning steps
5 / 12.5 kHz
Memories
300 channels in bank(s) @ 50 channels/second

Receiver

RX-range
25-54 / 108-174 / 406-512 / 806-956 MHz
Modulations
AM   FM   W-FM
Sensitivity
25-28: 0.4 μV
28-54: 0.2 μV
108-137: 0.4 μV
137-174: 0.2 μV
406-512:0.3 μV
806-956: 0.4 μV
(12 dB SINAD)

Close-call
25-54: 450 μV
137-174: 150 μV
406-512: 130 μV
108-137: 200 μV
806-956: 450 μV
Selectivity
?
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
1.2 W

Connections

Antenna
BNC
Impedance
50Ω
Other
-

Electrical

Power requirements
13.8V DC
Current drain RX
?
TX
-

Physical

Dimensions (w×h×d)
132 × 41 × 146 mm (5.20 × 1.61 × 5.75 in)
Weight
?
Form factor
Mobile
Manufactured
Between 200x and 200x

Other features

Usage
Amateur / Ham radio operators
Features + options
Close-call
Backlit Display
~3600 Pre-programmed channels
Accessories
-
RigReference ID
5102
MPN
UNIDEN-BEARCAT-BC000355C

Manuals, diagrams and brochures

No documents available for this particular model.

Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Uniden-Bearcat BC355C. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the Uniden-Bearcat BC355C is around:

  • EUR 57.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2013 EUR 79.95 Used / Good thiecom.de
