General characteristics

HAM bands
160m  80m  60m  40m  30m (WARC)  20m  17m (WARC)  15m  12m (WARC)  11m (CB)  10m
Frequency stability
?
Tuning steps
100 Hz
Memories
?

Receiver

RX-range
1.5-30 MHz
Modulations
AM   CW   SSB
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
requires headphones / external speaker

Transmitter

TX-range
1.5-30 MHz
Modulations
AM   CW   SSB
RF-output
40 W, 25 W, 5 W (PEP)

Connections

Antenna
BNC + Proprietary (military)
Impedance
50Ω
Other
-

Electrical

Power requirements
20-32V DC (28V nominal)
Current drain RX
30 W
TX
140 W

Physical

Dimensions (w×h×d)
230 × 220 × 336 mm (9.06 × 8.66 × 13.23 in)
Weight
26.00 kg (57.4 lbs)
Form factor
Mobile
Manufactured
Between 197x and 20xx in MEL Communications Ltd in Crawley, England

Other features

Usage
Military communication
Features + options
-
Accessories
-
RigReference ID
5116
MPN
CLANSMAN-VRC-000321
