RadioShack / Realistic SX-190 Desktop Shortwave receiver

 (0.0/5)  Add a story   View all stories (0)   Add to my shack



Login or Register to upload images

The RadioShack AX-190 (also sold under the Allied brand name) is a general coverage receiver. It covers all short-wave bands between 80 and 10 meters (3.5-4, 5.7-6.2, 7-7.5, 9.5-10, 11.5-12, 14-14.5, 15-15.5, 17.5-18 and 27-27.5 MHz) plus one optional 500 kHz band. An external speaker was available in the form of the SP-190.

Original price: USD 250.00

Frequency range

RX-range
80-10m
TX-range
-
HAM bands
-
Stability
-
Tuning steps
-
Filters
-

Receiver

Modulations
AM   CW   USB   LSB
Sensitivity
-
Selectivity
4 kHz
Receiver system
Double conversion superheterodyne
IF-frequencies
-
Image rejection
-
Audio output
-

Transmitter

Modulations
-
RF-Output
-

Connections

Antenna
SO-239
Impedance
50/75 Ω

Electrical

Power requirements
Mains or 12V DC
Current drain RX
-
TX
-

Physical

Dimensions (w×h×d)
381 × 178 × 254 mm (15.00 × 7.01 × 10.00 in)
Weight
9.00 kg (19.9 lbs)
Form factor
Base Station
Manufactured
Between 1971 and 1973
MPN

Other features

Memories
-
Usage
Amateur / Ham radio operators
Features + options
¼" Head. Jack, S-Meter, Preselector, NL, Calibrator, AGC, Q-Multiplier, Record Jack, Mute Line, RF Gain, HFO Output.
