The GRC-3030 was used by the Dutch armed forces between 1958 and 1970 as a vehicle mounted radio. It was replacing the aged Wireless Set 19. The GRC-3030 covers 2-12 MHz in 3 bands: 2-3.7, 3.6-6.7 and 6.6-12 MHz and supports AM and CW. The DY-3030 / GRC-3030 power supply unit converts 24V DC to the required internal voltages.
General characteristics
- HAM bands
- ?
- Frequency stability
- ?
- Tuning steps
- ?
- Memories
- ?
Receiver
- RX-range
- 2-12 MHz
- Modulations
- AM CW
- Sensitivity
- ?
- Selectivity
- ?
- Filters
- ?
- Receiver system
- Single conversion
- IF-frequencies
- 465 kHz
- Image rejection
- ?
- Audio output
- ?
Transmitter
- TX-range
- 2-12 MHz
- Modulations
- AM CW
- RF-output
- 10/12.5 W
Connections
- Antenna
- BNC + Proprietary (military)
- Impedance
- 50Ω
- Other
- -
Electrical
- Power requirements
- 24V DC
- Current drain RX
- ?
- TX
- ?
Physical
- Dimensions (w×h×d)
- 245 × 475 × 295 mm (9.65 × 18.70 × 11.61 in)
- Weight
- 21.50 kg (47.4 lbs)
- Form factor
- Mobile
- Manufactured
- Between 1958 and 1970 in Netherlands
Other features
- Usage
- Military communication
- Features + options
- -
- Accessories
- -
- RigReference ID
- 5179
- MPN
- VAN-DER-HEEM-GRC-003030
Manuals, diagrams and brochures
- GRC-3030 Circuit Diagram PDF - Unknown size, submitted by RigReference
- GRC-3030 Alignment procedure (Dutch) PDF - Unknown size, submitted by RigReference
- Upload relevant documents
New and second-hand prices
Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Van der Heem GRC-3030. Just bought or sold this model? Let us know what you traded it for and help other ham operators!
Based on historic data, today's second-hand price of the Van der Heem GRC-3030 is around:
- EUR 24.00 ~ EUR 19.00
These estimates are based on the following prices:
