General characteristics

HAM bands
?
Frequency stability
?
Tuning steps
?
Memories
128 channels in 1 bank(s)

Receiver

RX-range
68-88 MHz
136-174 MHz
403-470 MHz
Modulations
FM
Sensitivity
< 0.35 µV (12 dB SINAD)
Selectivity
> 60 dB (12.5 kHz)
> 70 dB (20/25 kHz)
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
> 70 dB
Audio output
?

Transmitter

TX-range
68-88 MHz
136-174 MHz
403-470 MHz
Modulations
FM
RF-output
5/25 W

Connections

Antenna
-
Impedance
50Ω
Other
-

Electrical

Power requirements
13.8V DC
Current drain RX
?
TX
?

Physical

Dimensions (w×h×d)
168 × 44 × 160 mm (6.61 × 1.73 × 6.30 in)
Weight
1.05 kg (2.3 lbs)
Form factor
Mobile
Manufactured
Between 200x and 20xx

Other features

Usage
Commercial / Land mobile communication
Features + options
Select 5/5-tone selcall. CTCSS/PL. Split mounting option.
Accessories
-
RigReference ID
5216
MPN
MOTOROLA-GM-000950-N3

Manuals, diagrams and brochures

No documents available for this particular model.

Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Motorola GM-950 N3. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

These estimates are based on the following prices:

Year Historic price Condition Submitted by
