General characteristics

HAM bands
?
Frequency stability
?
Tuning steps
?
Memories
?

Receiver

RX-range
0.05-30 MHz
Modulations
AM   AM-sync   CW   SSB
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
DSP
IF-frequencies
?
Image rejection
?
Audio output
?

Connections

Antenna
N-type
Impedance
50/450Ω
Other
-

Electrical

Power requirements
Mains
Current drain RX
35 W
TX
-

Physical

Dimensions (w×h×d)
482 × 133 × 508 mm (18.98 × 5.24 × 20.00 in)
Weight
6.80 kg (15.0 lbs)
Form factor
Base Station
Manufactured
Between 19xx and 19xx in USA

Other features

Usage
Military communication
Features + options
-
Accessories
-
RigReference ID
5331
MPN
WATKINS-JOHNSON-HF-001000A

Manuals, diagrams and brochures

No documents available for this particular model.
