The Heathkit EK-2B is an educational kit radio from the early 1960's. It was preceded by the EK-2A and EK-1.

General characteristics

HAM bands
?
Frequency stability
?
Tuning steps
?

Receiver

RX-range
540-1600 kHz / 3-10 MHz
Modulations
AM
Sensitivity
20 mV (10 dB S/N)
Selectivity
8 kHz (-6 dB)
Filters
?
Receiver system
Single conversion
IF-frequencies
455 kHz
Image rejection
?
Audio output
?

Connections

Antenna
Clamps / screws
Impedance
50 Ω
Other
-

Electrical

Power requirements
Mains (105-125 V AC)
Current drain RX
40 W
TX
-

Physical

Manufactured
Between 1961 and 196x in USA
Dimensions (w×h×d)
292 × 165 × 190 mm (11.50 × 6.50 × 7.48 in)
Weight
1.80 kg (4.0 lbs)
Form factor
Base Station

Other features

Memories
?
Usage
Amateur / Ham radio operators
Features + options
?
Accessories
?
MPN
HEATHKIT-EK-000002B
