The Ten-Tec 599 Eagle is a transceiver combining simplified controls and ease of operation with the excellent performance of a low first IF 160-through 6-meter ham-band architecture in a compact, mobile-friendly structure. The analog portion of the radio is double conversion with IF frequencies of 9.0015 MHz and 22.5 kHz. A third conversion to zero-frequency IF is accomplished in the DSP processor.
Same as the Ten-Tec Eagle (599) with added built-in antenna tuner.
General characteristics
- HAM bands
- 160m 80m 60m 40m 30m (WARC) 20m 17m (WARC) 15m 12m (WARC) 6m 10m
- Frequency stability
- ± 0.5 p.p.m.
- Tuning steps
- 1 / 10 / 100 Hz / 1 / 10 kHz
- Memories
- 100 channels in 1 bank(s)
Receiver
- RX-range
- 0.5-30 / 50-54 MHz
- Modulations
- AM FM CW USB LSB FSK AFSK
- Sensitivity
- SSB: 0.5 µV, 2.4khz, 10dB SINAD
AM: 1.3 µV, 30% Mod, 6kHz BW, 10dB SINAD
FM: 2.2 µV, 5kHz Dev, 16kHz BW, 10dB SINAD
all with preamp off - Selectivity
- SSB/CW: 2.4 kHz
AM: 6 kHz
FM: 12 kHz - Filters
- Optional 300, 600, 1k, 1.8k, 6k, 15k
- Receiver system
- Double conversion + DSP
- IF-frequencies
- 1st: 9.0015 MHz
2nd: 22.5 kHz
3rd: 0 Hz (DSP) - Image rejection
- 1st IF: >90dB/HF bands,>70dB/6M 2nd IF: >73dB
- Audio output
- 2W into 4 ohms, <3% THD
Transmitter
- TX-range
- 160-10 m + WARC + 6 m
- Modulations
- AM FM CW USB LSB FSK AFSK
- RF-output
- 5-100 W (100% duty cycle)
Connections
- Antenna
- SO-239
- Impedance
- 50Ω
- Other
- -
Electrical
- Power requirements
- 13.8V DC ±15%
- Current drain RX
- 1.25 A
- TX
- 20 A
Physical
- Dimensions (w×h×d)
- 216 × 74 × 311 mm (8.50 × 2.91 × 12.24 in) excluding knobs and connectors
- Weight
- 3.30 kg (7.3 lbs) with all options
- Form factor
- Base Station
- Manufactured
- Between 2010 and 20xx in USA
Other features
- Usage
- Amateur / Ham radio operators
- Features + options
- IF-DSP
CTCSS
USB-connector
Color display - Accessories
- -
- RigReference ID
- 5439
- MPN
- TEN-TEC-EAGLE-(000599AT)
