General characteristics

HAM bands
?
Frequency stability
?
Tuning steps
?
Memories
?

Receiver

RX-range
0.1-30 MHz
Modulations
AM   USB   LSB   ISB
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
Double / triple conversion
IF-frequencies
?
Image rejection
?
Audio output
2 W

Connections

Antenna
SO-239
Impedance
50Ω
Other
-

Electrical

Power requirements
Mains (120/240 V AC)
Current drain RX
?
TX
-

Physical

Dimensions (w×h×d)
330 × 140 × 290 mm (12.99 × 5.51 × 11.42 in)
Weight
7.70 kg (17.0 lbs)
Form factor
Base Station
Manufactured
Between 1971 and 19xx

Other features

Usage
Commercial / Land mobile communication
Features + options
Nixie tube display
BFO
Noise blanker
Accessories
-
RigReference ID
5579
MPN
DRAKE-DSR-000001
