General characteristics

HAM bands
2m
Frequency stability
?
Tuning steps
5 kHz
Memories
800 channels in 1 bank(s)

Receiver

RX-range
144-148 MHz
Modulations
FM
Sensitivity
≥ 0.3 mV for 20 dB SINAD
Selectivity
?
Filters
?
Receiver system
PLL synthesizer
IF-frequencies
?
Image rejection
65 dB
Audio output
0.5 W @ 10% THD

Transmitter

TX-range
144-148 MHz
Modulations
FM
RF-output
≥ 1.5 W

Connections

Antenna
BNC + Built-in telescopic
Impedance
50Ω
Other
-

Electrical

Power requirements
9.6 V DC (8 × NiCd)
Current drain RX
17 mA
TX
400 mA max

Physical

Dimensions (w×h×d)
62 × 165 × 40 mm (2.44 × 6.50 × 1.57 in)
Weight
400 gr (14.1 oz)
Form factor
Handheld
Manufactured
Between 1979 and 198x

Other features

Usage
Amateur / Ham radio operators
Features + options
-
Accessories
-
RigReference ID
5897
MPN
TEMPO-SYNCOM-S000001

Manuals, diagrams and brochures

Tempo S1 Operating Instructions PDF - Unknown size, submitted by RigReference
