General characteristics

HAM bands
None
Frequency stability
?
Tuning steps
?
Memories
100 channels in 10 bank(s)

Receiver

RX-range
118-140 MHz
Modulations
AM
Sensitivity
0.75 µV (10 dB S+N/N)
Selectivity
?
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
?

Connections

Antenna
BNC + SO-239
Impedance
50Ω
Other
-

Electrical

Power requirements
11-14 V DC
Current drain RX
300 mA max
TX
-

Physical

Dimensions (w×h×d)
160 × 46 × 120 mm (6.30 × 1.81 × 4.72 in)
Weight
?
Form factor
Mobile
Manufactured
Between 1984 and 1987 in Japan

Other features

Usage
Amateur / Ham radio operators
Features + options
-
Accessories
-
RigReference ID
5963
MPN
SIGNAL-COMMUNICATIONS-CORP.-R-000532
