The ICOM IC-2700H is introduced by the newly established Noble Radio in 2013. The VHF transceiver covers both 6 meter and the somewhat unusual 4 meter band (70 MHz) in CW and SSB. The rig does not support FM, which is popular among _green radio_ enthusiasts on these bands.
General characteristics
- HAM bands
- 6m 2m
- Frequency stability
- ?
- Tuning steps
- 10 Hz, variable speed
- Memories
- 20 channels in 2 bank(s)
Receiver
- RX-range
- 69.9-70.5 (4m) / 50-52 (6m) MHz
- Modulations
- CW USB LSB
- Sensitivity
- MDS = -130 dbm
- Selectivity
- 500 Hz to 4 kHz adjustable with the SCAF filters
- Filters
- 15 kHz
- Receiver system
- Double conversion, down-converting design. Side-band elimination using phasing techniques with digitally generated Quadrature carriers and Image Reject Mixers preceded by 15 kHz crystal roofing filters.
- IF-frequencies
- 1st: 10.7 MHz
2nd: 25 kHz - Image rejection
- ?
- Audio output
- ?
Transmitter
- TX-range
- 69.9-70.5 (4m) / 50-52 (6m) MHz
- Modulations
- CW USB LSB
- RF-output
- 20 Watts CW or PEP SSB
Connections
- Antenna
- -
- Impedance
- 50Ω
- Other
- -
Electrical
- Power requirements
- 11.5-14 V DC
- Current drain RX
- ?
- TX
- 3.6 A max
Physical
- Dimensions (w×h×d)
- 203 × 95 × 305 mm (7.99 × 3.74 × 12.01 in)
- Weight
- 1.80 kg (4.0 lbs)
- Form factor
- Mobile
- Manufactured
- Between 2013 and 20xx in USA
Other features
- Usage
- Amateur / Ham radio operators
- Features + options
- Fully PC-controllable
10.7 MHz IF-signal output - Accessories
- -
- RigReference ID
- 6025
- MPN
- NOBLE-RADIO-NR-000006N4
Manuals, diagrams and brochures
- Noble Radio NR-6N4 Preliminary technical specs PDF - Unknown size, submitted by RigReference
- Upload relevant documents
New and second-hand prices
Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Noble Radio NR-6N4. Just bought or sold this model? Let us know what you traded it for and help other ham operators!
Based on similar Transceiver equipment, the estimated value of the Noble Radio NR-6N4 is around:
- USD 207 ~ USD 384
This estimate is based on similar equipment and may not reflect the exact value of this model.
These estimates are based on the following prices:
