General characteristics

HAM bands
?
Frequency stability
2.5 p.p.m.
Tuning steps
?
Memories
?

Receiver

RX-range
30-512 MHz
762-870 MHz optional
Modulations
AM   FM   FSK   PSK31/63
Sensitivity
SSB: –113 dBm (0.5 µv) minimum for 10 dB sinad
Selectivity
?
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
≥ 80 dB
Audio output
15 mW at 1000 ohm to external handset

Transmitter

TX-range
30-512 MHz
762-870 MHz optional
Modulations
AM   FM   FSK   PSK31/63
RF-output
0.25-5 W, 10 W SATCOM burst mode

Connections

Antenna
TNC
Impedance
50Ω
Other
-

Electrical

Power requirements
Li-ion battery
Current drain RX
?
TX
?

Physical

Dimensions (w×h×d)
74 × 244 × 64 mm (2.91 × 9.61 × 2.52 in) with battery and GPS
Weight
1.18 kg (2.6 lbs) with batteries
Form factor
Handheld
Manufactured
Between 20xx and 20xx in USA

Other features

Usage
Military communication
Features + options
-
Accessories
-
RigReference ID
6048
MPN
HARRIS-AN/PRC-000152
