General characteristics

HAM bands
2m
Frequency stability
?
Tuning steps
?

Receiver

RX-range
2m (144.0-145.0 MHz)
Modulations
CW   SSB
Sensitivity
0.5 µV (S/N > 10 dB)
Selectivity
2.4 kHz @ -6 dB
4.8 kHz @ -60 dB
Filters
?
Receiver system
Single superheterodyne
IF-frequencies
10.7 MHz
Image rejection
≥ 60 dB
Audio output
1.5 W @ 10% THD, 8 Ohm

Transmitter

TX-range
2m (144.0-145.0 MHz)
Modulations
CW   SSB
RF-Output
8 W

Connections

Antenna
SO-239
Impedance
50Ω
Other
-

Electrical

Power requirements
13.8V DC
Current drain RX
600 mA
TX
3 A

Physical

Manufactured
Between 197x and 19xx
Dimensions (w×h×d)
180 × 60 × 240 mm (7.09 × 2.36 × 9.45 in)
Weight
2.70 kg (6.0 lbs)
Form factor
Mobile

Other features

Memories
40 channels in 1 bank(s)
Usage
Amateur / Ham radio operators
Features + options
?
Accessories
?
MPN
KENWOOD-TR-007010

Manuals, diagrams and brochures

No documents available for this particular model.

Upload relevant documents

Show other documents.
Find the Kenwood TR-7010 user manuals on eBay

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Kenwood TR-7010. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Year Historic price Condition Submitted by
