Alinco DR-735T Mobile VHF/UHF Transceiver

 (0.0/5)  Add a story   View all stories (0)   Add to my shack



Login or Register to upload images

DV (Digital Voice) option with EJ-47U

Frequency range

RX-range
108-174 / 430-480 MHz
TX-range
144-148 / 430-450 MHz
HAM bands
2m  70cm
Stability
+/- 2.5 p.p.m.
Tuning steps
5 / 6.25 / 8.33 / 10 / 12.5 / 15 / 20 / 25 / 30 / 50 / 100 kHz
Filters
-

Receiver

Modulations
AM   FM   N-FM   W-FM   DV
Sensitivity
0.2 µV (12 dB SINAD)
Selectivity
FM: 15 kHz (-6 dB), 30 kHz (-50 dB)
N-FM: 9 kHz (-6 dB), 20 kHz (-50 dB)
Receiver system
Double conversion superheterodyne
IF-frequencies
1st IF: 21.7 MHz (VHF), 30.85 MHz (UHF)
2nd IF: 450 kHz (VHF), 455 kHz (UHF)
Image rejection
-
Audio output
2 W at 10% distortion / 8 ohms

Transmitter

Modulations
FM   N-FM   DV
RF-Output
5 .. 50 W

Connections

Antenna
SO-239
Impedance
50Ω

Electrical

Power requirements
13.8V DC +/- 15%
Current drain RX
400-600 mA
TX
12 A max

Physical

Dimensions (w×h×d)
140 × 60 × 188 mm (5.51 × 2.36 × 7.40 in)
Weight
1.30 kg (2.9 lbs)
Form factor
Mobile
Manufactured
Between 2016 and 201x in Japan
MPN

Other features

Memories
1000 channels in 1 bank(s)
Usage
Amateur / Ham radio operators
Features + options
-
Accessories
EJ-47U DV option

Manuals, diagrams and brochures

No documents available for this particular model.

Upload relevant documents

Show other documents.

Stories & reviews

Do you know this rig? Tell us something about it!

What is it worth?

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the current value of the Alinco DR-735T. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's value of the Alinco DR-735T might be around:

  • USD 319.00
Price Condition Year User
USD 320.00 New / Mint 2018 RigReference
