Frequency range

RX-range
144-146 MHz
TX-range
144-146 MHz
HAM bands
2m
Stability
?
Tuning steps
10 / 100 kHz
Filters
?

Receiver

Modulations
FM
Sensitivity
?
Selectivity
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
?

Transmitter

Modulations
FM
RF-Output
1 / 10 W

Connections

Antenna
SO-239
Impedance
50Ω

Electrical

Power requirements
13.8 V DC
Current drain RX
?
TX
?

Physical

Dimensions (w×h×d)
?
Weight
?
Form factor
Mobile
Manufactured
Between 19xx and 19xx in Japan
MPN
BELCOM-LS-000020F

Other features

Memories
3 channels in 1 bank(s)
Usage
Amateur / Ham radio operators
