Extended frequency coverage with optional 10x crystal oscillator. By April 1979, more than 15000 units had been sold worldwide

General characteristics

HAM bands
80m  40m  20m  15m  10m
Frequency stability
?
Tuning steps
Continuous
Memories
None

Receiver

RX-range
10-80 m
Modulations
CW   USB   LSB
Sensitivity
15-160 m: 0.4 µV (10 dB S/N)
10 m: 0.6 µV (10 dB S/N)
Selectivity
2.7 kHz (-6 dB) / 4.3 kHz (-60 dB)
Filters
?
Receiver system
Single conversion superheterodyne
IF-frequencies
5.52 MHz
Image rejection
60 dB
Audio output
2 W / 3.2 ohms

Transmitter

TX-range
10-80 m
Modulations
CW   USB   LSB
RF-output
50-100 W

Connections

Antenna
SO-239
Impedance
50Ω
Other
-

Electrical

Power requirements
13.8 V DC
Current drain RX
300-500 mA
TX
16 A max

Physical

Dimensions (w×h×d)
240 × 90 × 250 mm (9.45 × 3.54 × 9.84 in)
Weight
3.10 kg (6.8 lbs)
Form factor
Base Station
Manufactured
Between 1975 and 1979 in USA

Other features

Usage
Amateur / Ham radio operators
Features + options
100 kHz calibrator
Dimmer
Accessories
-
RigReference ID
6424
MPN
ATLAS-000210

Manuals, diagrams and brochures

Atlas-210 ADD Sidetone PDF - 43.3 kB, submitted by Berend

Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Atlas 210. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the Atlas 210 is around:

  • USD 8.00 ~ USD 8.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
1977 USD 675.00 New / Mint RigReference
1975 USD 649.00 New / Mint RigReference
