General characteristics

HAM bands
160m  80m  60m  40m  30m (WARC)  20m  17m (WARC)  15m  12m (WARC)  11m (CB)  10m
Frequency stability
-
Tuning steps
-
Memories
None

Frequency range

Range
160-6 MHz

Connections

Antenna
SO-239
Impedance
50/75Ω
Other
-

Electrical

Power requirements
None
Current drain RX
-
TX
-

Physical

Dimensions (w×h×d)
184 × 121 × 108 mm (7.24 × 4.76 × 4.25 in)
Weight
1.40 kg (3.1 lbs)
Form factor
Base Station
Manufactured
Between 1962 and 1965 in USA

Other features

Usage
Amateur / Ham radio operators
Features + options
-
Accessories
-
RigReference ID
6591
MPN
HEATHKIT-HM-000011

Manuals, diagrams and brochures

Heathkit HM-11 Assembly and Operation Manual PDF - 2.31 MB, submitted by Wim

Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Heathkit HM-11. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

These estimates are based on the following prices:

Year Historic price Condition Submitted by
