Anytone AT-D890UV

General characteristics

HAM bands

2m  70cm

Frequency stability

±2.5 p.p.m. @ -20 to +55°C (-4 to +131°F)

Tuning steps

5 / 6.25 / 8.33 kHz

Memories

4000 channels in 1 bank(s)

Receiver

RX-range

136-174 / 400-480 MHz

Modulations

AM   FM   N-FM   DMR   NXDN

Sensitivity

FM: 0.25 µV (12 dB SINAD)
N-FM: 0.35 µV (12 dB SINAD)
DMR: 0.3 µV (BER 5%)

Selectivity

FM: 65 dB (Adjacent channel)
N-FM: 60 dB (Adjacent channel)

Filters

?

Receiver system

?

IF-frequencies

?

Image rejection

≥ 60 dB

Audio output

1 W at 5% distortion / 16 ohm

Transmitter

TX-range

87.5-108 / 108-174 / 400-480 MHz

Modulations

FM   N-FM   DMR   NXDN

RF-output

7 / 5 / 2.5 / 0.2 W

Connections

Antenna

SMA

Impedance

50Ω

Other

-

Electrical

Power requirements

7.4 V DC

Current drain RX

?

TX

?

Physical

Dimensions (w×h×d)

61 × 129 × 42 mm (2.40 × 5.08 × 1.65 in)

Weight

293 gr (10.3 oz) with battery

Form factor

Handheld

Manufactured

Between 2025 and 20xx in China

Other features

Usage

Amateur / Ham radio operators

Features + options

DMR APRS reporting
1.7" TFT display
10000 talk groups and 150000 contacts
Auto-sense DMR or FM reception
GPS

Accessories

-

RigReference ID

6663

MPN

ANYTONE-AT-D000890UV

Manuals, diagrams and brochures

No documents available for this particular model.



Upload relevant documents

Reviews

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Anytone AT-D890UV. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the Anytone AT-D890UV is around:

• EUR 258.00
• USD 298.00
• GBP 219.00

Price History Chart

These estimates are based on the following prices:
