Speaker output impedance: 4-16 ohm. Headphone impedance: 16-64 ohm.
General characteristics
- HAM bands
- ?
- Frequency stability
- ?
- Tuning steps
- ?
- Memories
- ?
Audio
- Audio output
- ≥3 W (8 ohm, THD ≤0.2%); headphones 100 mW max
Connections
- Antenna
- -
- Impedance
- ?
- Other
- -
Electrical
- Power requirements
- 12 V DC ±15%
- Current drain RX
- ?
- TX
- ?
Physical
- Dimensions (w×h×d)
- 159 × 44 × 143 mm (6.26 × 1.73 × 5.63 in)
- Weight
- ?
- Form factor
- ?
- Manufactured
- Between 20xx and 20xx in China
Other features
- Usage
- Amateur / Ham radio operators
- Features + options
- Digital noise reduction, SNR improvement better than 22 dB
Digital filter: low cut 5-1280 Hz, high cut 500-5615 Hz
Selectable input impedance (16 ohm / 10 kohm)
Independent input and output volume
Dual audio outputs (3.5 mm stereo and RCA)
Headphone output with automatic speaker switching - Accessories
- -
- RigReference ID
- 6682
- MPN
- XIEGU-GNR000001
