This transceiver is wideband, using twice (30 kHz) the bandwidth compared to the more traditional 15 kHz used for decades on VHF/UHF ham bands. The audio quality is probably amazing between two equal units.
General characteristics
- HAM bands
- 70cm
- Frequency stability
- ±0.001% @ -10 to +60°C (14 to 140°F)
- Tuning steps
- 20 kHz
- Memories
- 4 channels in 1 bank(s)
Receiver
- RX-range
- 432-439.8 MHz
- Modulations
- FM
- Sensitivity
- 0.6 µV (20 dB noise quieting)
- Selectivity
- 30 kHz (-6 dB) / 60 kHz (-60 dB)
- Filters
- ?
- Receiver system
- Double conversion superheterodyne
- IF-frequencies
- 1st: 21.4 MHz
2nd: 455 kHz - Image rejection
- ?
- Audio output
- 2 W at 10% distortion / 8 ohm
Transmitter
- TX-range
- 432-439.8 MHz
- Modulations
- FM
- RF-output
- High: 10 W, Low: 1 W
Connections
- Antenna
- SO-239
- Impedance
- 50Ω
- Other
- -
Electrical
- Power requirements
- 13.8V DC ±15%
- Current drain RX
- 450-630 mA
- TX
- 1.6-3.5 A
Physical
- Dimensions (w×h×d)
- 156 × 58 × 228 mm (6.14 × 2.28 × 8.98 in)
- Weight
- 2.20 kg (4.9 lbs)
- Form factor
- Mobile
- Manufactured
- Between 19xx and 19xx in Japan
Other features
- Usage
- Amateur / Ham radio operators
- Features + options
- Detachable front panel
- Accessories
- -
- RigReference ID
- 3077
- MPN
- ICOM-IC-000370
