Microcomputer based 5 kHz step Digital PLL synthesizer. Independent Dual VFO Capability.
General characteristics
- HAM bands
- 70cm
- Frequency stability
- ± 0.001%
- Tuning steps
- 5 / 25 kHz
- Memories
- 5 channels in 1 bank(s)
Receiver
- RX-range
- 440-450 MHz
- Modulations
- FM
- Sensitivity
- ≤ 0.3 µV (12 dB SINAD)
≤ 0.4 µV (20 dB noise quieting) - Selectivity
- 7.5 kHz (-6 dB), 15 kHz (-60 dB)
- Filters
- ?
- Receiver system
- Double conversion superheterodyne
- IF-frequencies
- 21.8 MHz / 455 kHz
- Image rejection
- >60 dB
- Audio output
- 2 W
Transmitter
- TX-range
- 440-450 MHz
- Modulations
- FM
- RF-output
- High: 10 W, Low: 1 W
Connections
- Antenna
- N-type
- Impedance
- 50Ω
- Other
- -
Electrical
- Power requirements
- 13.8V DC
- Current drain RX
- 500-700 mA
- TX
- 1.7-3.5 A
Physical
- Dimensions (w×h×d)
- 140 × 50 × 177 mm (5.51 × 1.97 × 6.97 in)
- Weight
- 1.50 kg (3.3 lbs)
- Form factor
- Mobile
- Manufactured
- Between 1983 and 19xx in Japan
Other features
- Usage
- Amateur / Ham radio operators
- Features + options
- -
- Accessories
- -
- RigReference ID
- 3094
- MPN
- ICOM-IC-000045A
Manuals, diagrams and brochures
- Icom IC-45A/E Instruction Manual PDF - 3.57 MB, submitted by RigReference
- Upload relevant documents
New and second-hand prices
Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used ICOM IC-45A. Just bought or sold this model? Let us know what you traded it for and help other ham operators!
Based on historic data, today's second-hand price of the ICOM IC-45A is around:
- USD 45.00
