ICOM IC-756

General characteristics

HAM bands

160m  80m  40m  30m (WARC)  20m  17m (WARC)  15m  12m (WARC)  6m  10m

Frequency stability

Less than ±200 Hz from 1 min. to 60 min. after power ON. After that, the rate of stability change is less than ±30 Hz/hr at +25°C

Tuning steps

1 Hz

Memories

101 channels in 1 bank(s)

Receiver

RX-range

0.03-60 MHz

Modulations

AM   FM   CW   USB   LSB   RTTY

Sensitivity

SSB, CW, RTTY - 0.16 µV (1.80-29.99 MHz)*1
(10 dB S/N) - 0.13 µV (50.0-54.0 MHz)*2
AM - 13 µV (0.5-1.799 MHz)
(10 dB S/N) - 2 µV (1.80-29.99 MHz)*1
FM - 0.5 µV (28.0-29.99 MHz)*1
(12 dB SINAD) 0.32 µV (50.0-54.0 MHz)*2
*1 Pre-amp 1 ON, *2Pre-amp 2 ON
Squelch Sensitivity (threshold):
SSB, CW, RTTY - Less than 5.6 µV
FM - Less than 1.0 µV

Selectivity

SSB, CW, RTTY - More than 2.4 kHz/-6 dB ; Less than 3.8 kHz/-60 dB
AM - More than 9.0 kHz/-6 dB ; Less than 20 kHz/-60 dB
FM - More than 12 kHz/-6 dB ; Less than 30 kHz/-60 dB

Filters

?

Receiver system

?

IF-frequencies

?

Image rejection

?

Audio output

More than 2.0 W at 10% distortion with an 8 ohm load

Transmitter

TX-range

10-160 m + WARC/6 m

Modulations

AM   FM   CW   USB   LSB   RTTY

RF-output

5-100/5-100 W (5-40/5-40 W AM)

Connections

Antenna

SO-239 + RCA (Tulip)

Impedance

50Ω

Other

-

Electrical

Power requirements

13.8V DC

Current drain RX

2.7 A max

TX

20 A max

Physical

Dimensions (w×h×d)

340 × 111 × 285 mm (13.39 × 4.37 × 11.22 in)

Weight

9.30 kg (20.5 lbs)

Form factor

Base Station

Manufactured

Between 19xx and 19xx in Japan

Other features

Usage

Amateur / Ham radio operators

Features + options

DSP, Twin RX

Accessories

-

RigReference ID

3160

MPN

ICOM-IC-000756

Manuals, diagrams and brochures

ICOM IC-756 specs RTF - 3.7 kB, submitted by John Nicholas



Upload relevant documents

Reviews

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used ICOM IC-756. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic price data, today's estimated value of the ICOM IC-756 in Good condition is around:

• GBP 550
• USD 1,025 ~ USD 1,540
