DSP (UT-106) option.
General characteristics
- HAM bands
- 2m 70cm
- Frequency stability
- ?
- Tuning steps
- ?
- Memories
- 212 channels in 1 bank(s)
Receiver
- RX-range
- 136-174 / 420-480 MHz
1240-1320 MHz (with UX-910 option) - Modulations
- FM N-FM CW SSB
- Sensitivity
- FM: <0.18 µV (12 dB SINAD)
SSB/CW: <0.11 µV (10 dB S/N) - Selectivity
- FM: 15 kHz (-6 dB), 30 kHz (-60 dB)
FM-N: 6 kHz (-6 dB), 18 kHz (-60 dB)
SSB/CW: 2.3 kHz (-6 dB), 4.2 kHz (-60 dB)
CW-N: 0.5 kHz (-6 kHz), 1.34 kHz (-60 dB) - Filters
- ?
- Receiver system
- Single- double- or triple conversion superheterodyne, depending on band and mode IF frequency matrix
- IF-frequencies
- ?
- Image rejection
- 2m/70cm: >60 dB 23cm: >50 dB
- Audio output
- ?
Transmitter
- TX-range
- 144-146 / 430-440 MHz (Asia)
1260-1300 MHz/10 W (with UX-910 option) - Modulations
- FM N-FM CW SSB
- RF-output
- 5-50 / 5-50 W, 1-10 W on 23cm (with UX-910 option)
Connections
- Antenna
- N-type
- Impedance
- 50 Ω
- Other
- -
Electrical
- Power requirements
- 13.8V DC +/-15%
- Current drain RX
- Max 3.5 A (with UX-910)
- TX
- Max 23 A
Physical
- Dimensions (w×h×d)
- 241 × 94 × 239 mm (9.49 × 3.70 × 9.41 in)
- Weight
- 4.50 kg (9.9 lbs) without UX-910
- Form factor
- Base Station
- Manufactured
- Between 2000 and 200x in Japan
Other features
- Usage
- Amateur / Ham radio operators
- Features + options
- Dual 9K6 packet ports and built-in keyer. Twin RX
- Accessories
- -
- RigReference ID
- 3180
- MPN
- ICOM-IC-000910D
Manuals, diagrams and brochures
-
No documents available for this particular model.
- Upload relevant documents
New and second-hand prices
Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used ICOM IC-910D. Just bought or sold this model? Let us know what you traded it for and help other ham operators!
Based on historic data, today's second-hand price of the ICOM IC-910D is around:
- EUR 272.00
- USD 659.00
