Kenwood TM-251E

Mobile VHF Transceiver

Specs Manuals (1) Reviews (0) Prices (0) Compare

Find Kenwood TM-251E rigs and spare parts on eBay

The Kenwood TM-251E is a mobile VHF transceiver. It covers 144-146 / 430-440 MHz for receive and 144-146 MHz for transmit. The RF output power is selectable between High: 50 W, Medium: 10 W, and Low: 5 W. It features 1 memory bank with 41 channels and requires 13.8V DC power. The TM-251E is 9K6 packet ready. Dimensions are 40 × 140 × 160 mm. Current drain is Max 600 mA for receive and Max 11 A for transmit.

General characteristics

HAM bands: 2m 70cm
Frequency stability: ?
Tuning steps: ?
Memories: 41 channels in 1 bank(s)

Receiver

RX-range: 144-146 / 430-440 MHz
Modulations: FM
Sensitivity: ?
Selectivity: ?
Filters: ?
Receiver system: ?
IF-frequencies: ?
Image rejection: ?
Audio output: ?

Transmitter

TX-range: 144-146 MHz
Modulations: FM
RF-output: High: 50 W, Medium: 10 W, Low: 5 W

Connections

Antenna: -
Impedance: 50 Ω
Other: -

Electrical

Power requirements: 13.8V DC
Current drain RX: Max 600 mA
TX: Max 11 A

Physical

Dimensions (w×h×d): 140 × 40 × 160 mm (5.51 × 1.57 × 6.30 in)
Weight: 1,000 gr (2.2 lbs)
Form factor: Mobile
Manufactured: Between 1994 and 19xx

Other features

Usage: Amateur / Ham radio operators
Features + options: 9K6 packet ready.
Accessories: -
RigReference ID: 3394
MPN: KENWOOD-TM-000251E

We do our best to be accurate, but if you've spotted something wrong or incomplete, please let us know!

Manuals, diagrams and brochures

: TM-251 Rev1 PDF - 7.84 MB, submitted by Berend

: Upload relevant documents
