FCC ID: AAO9ZA20-119

General characteristics

HAM bands
11m (CB)  6m  2m  1.25m  70cm  33cm  23cm  10m  4m
Frequency stability
?
Tuning steps
5 / 12.5 / 30 / 50 kHz
Memories
300 channels in 10 bank(s) @ 16 channels/second

Receiver

RX-range
25-520 / 760-1300 MHz (cellular blocked in the US)
Modulations
AM   FM   W-FM
Sensitivity
AM (20 dB S/N @ 60% modulation)
25-520 MHz: 2 µV
760-1100 MHz: 2 µV
1100-1300 MHz: 3 µV
FM (20 dB S/N @ 3 kHz deviation)
25-520 MHz: 0.5 µV
760-1100 MHz: 0.5 µV
1100-1300 MHz: 3 µV
W-FM (30 dB S/N @ 22.5 kHz deviation)
25-520 MHz: 3 µV
760-1100 MHz: 3 µV
1100-1300 MHz: 10 µV
Selectivity
AM/FM: 18 kHz (-6 dB) / 30 kHz (-50 dB)
W-FM: 300 kHz (-6 dB) / 600 kHz (-50 dB)
Filters
?
Receiver system
Triple conversion superheterodyne
IF-frequencies
?
Image rejection
?
Audio output
1.8 W

Connections

Antenna
BNC
Impedance
50Ω
Other
-

Electrical

Power requirements
13.8 V DC or mains
Current drain RX
12 W
TX
-

Physical

Dimensions (w×h×d)
275 × 75 × 230 mm (10.83 × 2.95 × 9.06 in)
Weight
3.20 kg (7.1 lbs)
Form factor
Base Station
Manufactured
Between 1986 and 1988 in Japan (by GRE)

Other features

Usage
Amateur / Ham radio operators
Features + options
Sound squelch
Tape out jack
10 dB attenuator
Dimmer
Membrane keypad
Accessories
-
RigReference ID
3846
MPN
RADIOSHACK-REALISTIC-PRO-002004

Manuals, diagrams and brochures

No documents available for this particular model.

Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used RadioShack / Realistic Pro-2004. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the RadioShack / Realistic Pro-2004 is around:

  • USD 23.00 ~ USD 0.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2020 USD 40.00 Used / Good eBay
2020 USD 24.20 Used / Okay eBay
2020 USD 89.00 Used / Mint eBay
2006 USD 10.00 Used / Good R1VINCE
1986 USD 399.95 New / Mint RigReference
