1 x 6LQ6 final. 12 VDC option

General characteristics

HAM bands
80m  40m  20m  15m  10m
Frequency stability
?
Tuning steps
?
Memories
?

Receiver

RX-range
10-80 m
3.5-4 / 7-7.3 / 14-14.35 / 21-21.45 / 28-29.7 MHz
Modulations
CW   SSB
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
? conversion superheterodyne
IF-frequencies
?
Image rejection
?
Audio output
?

Transmitter

TX-range
10-80 m
3.5-4 / 7-7.3 / 14-14.35 / 21-21.45 / 28-29.7 MHz
Modulations
CW   SSB
RF-output
SSB: 260 W (PEP input), CW: 180 W (input)

Connections

Antenna
SO-239
Impedance
50/75 Ω
Other
-

Electrical

Power requirements
Mains
Current drain RX
?
TX
?

Physical

Dimensions (w×h×d)
330 × 140 × 280 mm (12.99 × 5.51 × 11.02 in)
Weight
11.00 kg (24.3 lbs)
Form factor
Unknown
Manufactured
Between 19xx and 19xx

Other features

Usage
Amateur / Ham radio operators
Features + options
-
Accessories
-
RigReference ID
4116
MPN
SWAN-(CUBIC)-000270-CYGNET

Manuals, diagrams and brochures

No documents available for this particular model.

Upload relevant documents

Reviews

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Swan (Cubic) 270 Cygnet. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic price data, today's estimated value of the Swan (Cubic) 270 Cygnet in Good condition is around:

  • USD 201 ~ USD 320

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2020 USD 320.00 Used / Good Gerry
2019 USD 201.00 Used / Good Robert G Leach
