Introductory price 2001 in the US: $379.95.

General characteristics

HAM bands
6m
Frequency stability
?
Tuning steps
5 / 25 kHz
Memories
100 channels in 5 bank(s) @ 15 channels/second

Receiver

RX-range
29-54 / 108-174 / 406-512 / 806-956 MHz
Modulations
AM   FM   W-FM
Sensitivity
29 - 54: 0.4V
118 - 136: 0.8V
136 - 174: 0.4V
406 - 512: 0.5V
806 - 956: 1.0V
Selectivity
?
Filters
?
Receiver system
Double (older) or triple (newer) conversion
IF-frequencies
?
Image rejection
?
Audio output
2.5 W

Connections

Antenna
BNC + NMO
Impedance
50Ω
Other
Older model has BNC connector, newer has NMO (Motorola)

Electrical

Power requirements
13.8V DC
Current drain RX
700 mA max
TX
-

Physical

Dimensions (w×h×d)
176 × 61 × 167 mm (6.93 × 2.40 × 6.57 in)
Weight
1.33 kg (2.9 lbs)
Form factor
Mobile
Manufactured
Between 1988 and 200x

Other features

Usage
Amateur / Ham radio operators
Features + options
Trunktracker III, tracks Motorola, EDACS and LTR systems
SAME w/FIPS
CTCSS / DCS
PC programmable
Accessories
-
RigReference ID
4458
MPN
UNIDEN-BEARCAT-BC000760XLT

Manuals, diagrams and brochures

No documents available for this particular model.

Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Uniden-Bearcat BC760XLT. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the Uniden-Bearcat BC760XLT is around:

  • EUR 31.00
  • USD 14.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2021 EUR 32.00 Used / Good SWL_de
2001 USD 379.95 New / Mint RigReference
