Lafayette HA-410

General characteristics

HAM bands

11m (CB)

Frequency stability

?

Tuning steps

?

Memories

?

Receiver

RX-range

28-29.7 MHz

Modulations

AM

Sensitivity

Less then 1 mV for 10 dB S/N

Selectivity

±3kHz at 6dB down, less then ±12kHz at 50dB down

Filters

?

Receiver system

Double conversion superheterodyne

IF-frequencies

1st: 5745 kHz
2nd: 455 kHz

Image rejection

?

Audio output

4 W @ 8 ohms

Transmitter

TX-range

28-29.7 MHz

Modulations

AM

RF-output

10

Connections

Antenna

SO-239

Impedance

50Ω

Other

-

Electrical

Power requirements

12V DC or mains (160 W max)

Current drain RX

?

TX

14 A max

Physical

Dimensions (w×h×d)

308 × 130 × 235 mm (12.13 × 5.12 × 9.25 in)

Weight

8.60 kg (19.0 lbs)

Form factor

Base Station

Manufactured

Between 19xx and 19xx

Other features

Usage

Amateur / Ham radio operators

Features + options

-

Accessories

-

RigReference ID

4483

MPN

LAFAYETTE-HA-000410
