The Sailor T2130 is a base station transceiver. It covers 0.1-30 MHz for reception and 1.6-30 MHz for transmission. Frequency stability is better than 0.34 p.p.m. The RF output is 250 W PEP. It features a double conversion super heterodyne receiver system with IF frequencies of 70 MHz (1st) and 10.73 MHz (2nd). Image rejection is ≥ 70 dB. This transceiver has one memory bank with 100 channels. The Sailor T2130 requires 24 V DC power and draws 0.9 A in receive mode and 13 A max in transmit mode. It weighs 4.5 kg. Features include quick selection of 2182 kHz and a built-in two tone alarm (1300 Hz and 2200 Hz) lasting 45 seconds.
General characteristics
- HAM bands
- 160m 80m 60m 40m 30m (WARC) 20m 17m (WARC) 15m 12m (WARC) 11m (CB) 10m
- Frequency stability
- Better than 0.34 p.p.m.
- Tuning steps
- ?
- Memories
- 100 channels in 1 bank(s)
Receiver
- RX-range
- 0.1-30 MHz
- Modulations
- AM USB LSB
- Sensitivity
- J3E (SSB) <10 dB/µV for 20 dB SINAD
H3E (AM) <24 dB/µV for 20 dB SINAD - Selectivity
- J3E (SSB) 350 Hz to 2700 Hz at -6 dB
H3E (AM) ±3.3 kHz at -6 dB - Filters
- ?
- Receiver system
- Double conversion super heterodyne
- IF-frequencies
- 1st IF 70 MHz. 2nd 10.73 MHz
- Image rejection
- ≥ 70 dB
- Audio output
- ?
Transmitter
- TX-range
- 1.6-30 MHz
- Modulations
- AM USB LSB
- RF-output
- 250 W (PEP)
Connections
- Antenna
- -
- Impedance
- 50Ω
- Other
- -
Electrical
- Power requirements
- 24 V DC - 10% +30%
- Current drain RX
- 0.9 A
- TX
- 13 A max
Physical
- Dimensions (w×h×d)
- ?
- Weight
- 4.50 kg (9.9 lbs)
- Form factor
- Base Station
- Manufactured
- Between 19xx and 19xx in Denmark
Other features
- Usage
- Marine / Navy
- Features + options
- Quick selection of 2182 kHz
Built-in two tone alarm: 1300 Hz and 2200 Hz with a duration of 45 secs - Accessories
- -
- RigReference ID
- 5546
- MPN
- SAILOR-T002130
