Price when new in 2013: USD 346,-

General characteristics

HAM bands
80m  40m  30m (WARC)  20m  17m (WARC)  15m  12m (WARC)  10m
Frequency stability
?
Tuning steps
0.01 / 0.1 / 1 / 10 / 100 kHz
Memories
100 channels in 1 bank(s)

Receiver

RX-range
30 kHz - 29.999 MHz
Modulations
AM   FM   CW   SSB
Sensitivity
CW: 0.2 µV / 10 dB
AM: 1 µV / 10 dB
FM: 0.2 µV
Selectivity
2.4 kHz @ -6 dB
3.6 kHz @ -40 dB
AM: 6 kHz
CW: 200-1200 kHz
Filters
?
Receiver system
Double (AM/CW/SSB) / triple (FM) conversion
IF-frequencies
1st: 45 MHz
2nd: 12 MHz
3rd: 455 kHz (FM-only)
Image rejection
70 dB
Audio output
internal speaker

Transmitter

TX-range
80-10 m
Modulations
FM   CW   SSB
RF-output
1-10 W

Connections

Antenna
SO-239
Impedance
50Ω
Other
-

Electrical

Power requirements
13.8 V DC
Current drain RX
700 mA
TX
4 A

Physical

Dimensions (w×h×d)
230 × 230 × 90 mm (9.06 × 9.06 × 3.54 in)
Weight
3.50 kg (7.7 lbs)
Form factor
Base Station
Manufactured
Between 2013 and 20xx in China

Other features

Usage
Amateur / Ham radio operators
Features + options
USB interface
LCD display
Built-in keyer
Built-in ATU
Accessories
-
RigReference ID
6014
MPN
CHINESE-KN-000920

Manuals, diagrams and brochures

No documents available for this particular model.

Upload relevant documents

Reviews & stories

Rating Title Submitted
kn920 multi band transceiver 4 years ago by ccrjfk
KN-920 HF Radio 11 years ago by ve3fal

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Chinese KN-920. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the Chinese KN-920 is around:

  • EUR 109.00
  • USD 328.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2018 USD 400.00 New / Mint RigReference
2013 EUR 346.00 New / Mint RigReference
