The Youkits EK-1A is a 3 Band QRP CW transceiver. The frequency range for transmit is 7.0-7.3 / 10.1-10.15 / 14.0-14.3 MHz and the receive range is 7-16 MHz. The IF frequency is 60 MHz. RF output is 4-5 W at 13.8 V. It has 1 memory bank with 10 channels. Power requirements are 9-16 V DC. Features include a built-in keyer. Dimensions are 51 × 120 × 103 mm. Current drain is 120-130 mA in receive and 800 mA in transmit.
General characteristics
- HAM bands
- 20m 17m (WARC) 15m 6m
- Frequency stability
- ?
- Tuning steps
- ?
- Memories
- 10 channels in 1 bank(s)
Receiver
- RX-range
- 7-16 MHz
- Modulations
- CW
- Sensitivity
- ?
- Selectivity
- ?
- Filters
- ?
- Receiver system
- ?
- IF-frequencies
- IF-DDS: 60 MHz
- Image rejection
- ?
- Audio output
- ?
Transmitter
- TX-range
- 7.0-7.3 / 10.1-10.15 / 14.0-14.3 MHz
- Modulations
- CW
- RF-output
- 4-5 W @ 13.8 V
Connections
- Antenna
- BNC
- Impedance
- ?
- Other
- -
Electrical
- Power requirements
- 9-16 V DC
- Current drain RX
- 120-130 mA
- TX
- 800 mA
Physical
- Dimensions (w×h×d)
- 120 × 51 × 103 mm (4.72 × 2.01 × 4.06 in)
- Weight
- 420 gr (14.8 oz)
- Form factor
- Mobile
- Manufactured
- Between 2013 and 201x
Other features
- Usage
- Amateur / Ham radio operators
- Features + options
- Built-in keyer
- Accessories
- -
- RigReference ID
- 6032
- MPN
- YOUKITS-EK-000001A
Manuals, diagrams and brochures
-
No documents available for this particular model.
- Upload relevant documents
New and second-hand prices
Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Youkits EK-1A. Just bought or sold this model? Let us know what you traded it for and help other ham operators!
Based on historic price data, today's estimated value of the Youkits EK-1A in Good condition is around:
- USD 113
These estimates are based on the following prices:
