Three front ends of which two are independent phase coherent. Supported sampling rates: 48/96/192/384 kHz. Up to 1.152 MHz spectrum display. Full duplex, any split over the entire range. Ethernet connection. Diversity capable.
General characteristics
- HAM bands
- 160m 80m 60m 40m 30m (WARC) 20m 17m (WARC) 15m 12m (WARC) 11m (CB) 6m 10m
- Frequency stability
- ?
- Tuning steps
- 1 Hz, Software defined
- Memories
- ?
Receiver
- RX-range
- 0.01-55 MHz
- Modulations
- Multiple (Software defined)
- Sensitivity
- ?
- Selectivity
- Software defined
- Filters
- Software defined
- Receiver system
- Direct conversion
- IF-frequencies
- Software defined
- Image rejection
- ?
- Audio output
- 1 W
Transmitter
- TX-range
- 10-160 m + WARC / 6 m
- Modulations
- Multiple (Software defined)
- RF-output
- 1-100 W
Connections
- Antenna
- BNC
- Impedance
- 50Ω
- Other
- -
Electrical
- Power requirements
- 13.8 V DC
- Current drain RX
- ?
- TX
- ?
Physical
- Dimensions (w×h×d)
- 265 × 80 × 220 mm (10.43 × 3.15 × 8.66 in)
- Weight
- 4.50 kg (9.9 lbs)
- Form factor
- Headless
- Manufactured
- Between 2014 and 20xx in India
Other features
- Usage
- Amateur / Ham radio operators
- Features + options
- -
- Accessories
- -
- RigReference ID
- 6423
- MPN
- APACHE-LABS-ANAN-000200D
Manuals, diagrams and brochures
-
No documents available for this particular model.
- Upload relevant documents
New and second-hand prices
Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Apache Labs Anan-200D. Just bought or sold this model? Let us know what you traded it for and help other ham operators!
Based on historic price data, today's estimated value of the Apache Labs Anan-200D in Good condition is around:
- USD 262
These estimates are based on the following prices:
