ICOM IC-M810

Mobile Marine Transceiver

Specs Manuals (1) Reviews (0) Prices (0) Compare

Find ICOM IC-M810 rigs and spare parts on eBay

The ICOM IC-M810 is a mobile marine transceiver. It covers 0.5-30 MHz for reception and transmits on 2–3 / 4–5 / 6–7 / 8–9 / 12–14 / 16-17 / 18–19 / 22–23 / 25–26 MHz. Frequency stability is +/-15 Hz (below 23 MHz, at -30°C ~ +60°C) with 100 Hz tuning steps. It uses a double-conversion superheterodyne receiver system and has an RF output of 150 W max (60 W above 23 MHz). Audio output is 5 W from the internal speaker. The IC-M810 features 4 memory banks with 1005 channels, requires 13.6 V DC power, and weighs 6.5 kg. Dimensions are 112 × 287 × 62 mm. Current drain is 2 A max in receive mode and 30 A max in transmit mode.

General characteristics

HAM bands: None
Frequency stability: +/-15 Hz (below 23 MHz, at -30°C ~ +60°C)
Tuning steps: 100 Hz
Memories: 1005 channels in 4 bank(s)

Receiver

RX-range: 0.5-30 MHz
Modulations: AM CW USB LSB FSK RTTY
Sensitivity: *0.50000~1.79999 MHz*
SSB/CW/FSK 6.3 µV, AM 30 µV

*1.80000~30.0000 MHz*
SSB/CW/FSK 0.5 µV, AM 3.16 µV (For 12 dB SINAD)
Selectivity: SSB 2.3 kHz/-6 dB, 4.2 kHz/-60 dB
AM 6 kHz/-6 dB, 20 kHz/-60 dB
CW, FSK 500 Hz/-6 dB, 1.6 kHz/-60 dB* (*with optional FL-32A CW and RTTY Narrow Filter
Filters: ?
Receiver system: Double-conversion superheterodyne
IF-frequencies: SSB - 1st 69.0115, 2nd 9.0115
CW, FSK - 1st 69.0106, 2nd 9.0106
AM - 1st 69.0100, 2nd 9.0100 (Unit: MHz)
Image rejection: ?
Audio output: 5 W internal speaker

Transmitter

TX-range: 2–3 / 4–5 / 6–7 / 8–9 / 12–14 / 16-17 / 18–19 / 22–23 / 25–26 MHz (Approx)
Modulations: AM CW USB LSB FSK RTTY
RF-output: 150 W max (60 W above 23 MHz)

Connections

Antenna: SO-239
Impedance: 50Ω
Other: -

Electrical

Power requirements: 13.6 V DC
Current drain RX: 2 A max
TX: 30 A max

Physical

Dimensions (w×h×d): 287 × 112 × 62 mm (11.30 × 4.41 × 2.44 in)
Weight: 6.50 kg (14.3 lbs)
Form factor: Mobile
Manufactured: Between 19xx and 19xx in Japan

Other features

Usage: Marine / Navy
Features + options: -
Accessories: -
RigReference ID: 6626
MPN: ICOM-IC-M000810

We do our best to be accurate, but if you've spotted something wrong or incomplete, please let us know!

Manuals, diagrams and brochures

: Icom IC-M810 instruction manual PDF - 6.53 MB, submitted by RigReference
