ICOM IC-M810

Mobile Marine Transceiver

Specs Manuals (1) Reviews (0) Prices (0) Compare

The ICOM IC-M810 is a mobile marine transceiver. It covers 0.5-30 MHz for reception and transmits on 2–3 / 4–5 / 6–7 / 8–9 / 12–14 / 16-17 / 18–19 / 22–23 / 25–26 MHz. Frequency stability is +/-15 Hz (below 23 MHz, at -30°C ~ +60°C) with 100 Hz tuning steps. It uses a double-conversion superheterodyne receiver system and has an RF output of 150 W max (60 W above 23 MHz). Audio output is 5 W from the internal speaker. The IC-M810 features 4 memory banks with 1005 channels, requires 13.6 V DC power, and weighs 6.5 kg. Dimensions are 112 × 287 × 62 mm. Current drain is 2 A max in receive mode and 30 A max in transmit mode.

General characteristics

HAM bands: None
Frequency stability: +/-15 Hz (below 23 MHz, at -30°C ~ +60°C)
Tuning steps: 100 Hz
Memories: 1005 channels in 4 bank(s)

Receiver

RX-range: 0.5-30 MHz
Modulations: AM CW USB LSB FSK RTTY
Sensitivity: *0.50000~1.79999 MHz*
SSB/CW/FSK 6.3 µV, AM 30 µV

*1.80000~30.0000 MHz*
SSB/CW/FSK 0.5 µV, AM 3.16 µV (For 12 dB SINAD)
Selectivity: SSB 2.3 kHz/-6 dB, 4.2 kHz/-60 dB
AM 6 kHz/-6 dB, 20 kHz/-60 dB
CW, FSK 500 Hz/-6 dB, 1.6 kHz/-60 dB* (*with optional FL-32A CW and RTTY Narrow Filter
Filters: ?
Receiver system: Double-conversion superheterodyne
IF-frequencies: SSB - 1st 69.0115, 2nd 9.0115
CW, FSK - 1st 69.0106, 2nd 9.0106
AM - 1st 69.0100, 2nd 9.0100 (Unit: MHz)
Image rejection: ?
Audio output: 5 W internal speaker

Transmitter

TX-range: 2–3 / 4–5 / 6–7 / 8–9 / 12–14 / 16-17 / 18–19 / 22–23 / 25–26 MHz (Approx)
Modulations: AM CW USB LSB FSK RTTY
RF-output: 150 W max (60 W above 23 MHz)

Connections

Antenna: SO-239
Impedance: 50Ω
Other: -

Electrical

Power requirements: 13.6 V DC
Current drain RX: 2 A max
TX: 30 A max

Physical

Dimensions (w×h×d): 287 × 112 × 62 mm (11.30 × 4.41 × 2.44 in)
Weight: 6.50 kg (14.3 lbs)
Form factor: Mobile
Manufactured: Between 19xx and 19xx in Japan

Other features

Usage: Marine / Navy
Features + options: -
Accessories: -
RigReference ID: 6626
MPN: ICOM-IC-M000810

We do our best to be accurate, but if you've spotted something wrong or incomplete, please let us know!

Manuals, diagrams and brochures

: Icom IC-M810 instruction manual PDF - 6.53 MB, submitted by RigReference

: Upload relevant documents

Reviews

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used ICOM IC-M810. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on similar Transceiver equipment, the estimated value of the ICOM IC-M810 is around:

USD 210 ~ USD 390

This estimate is based on similar equipment and may not reflect the exact value of this model.
