New price 2000 in the UK: 195.00
General characteristics
- HAM bands
- 4m
- Frequency stability
- 10 p.p.m. over operating temp range
- Tuning steps
- 12.5 kHz
- Memories
- 20 channels in 1 bank(s)
Receiver
- RX-range
- 70.2500–70.4875 MHz
- Modulations
- FM
- Sensitivity
- <0.25mV for 12dB SINAD
- Selectivity
- ?
- Filters
- ?
- Receiver system
- ?
- IF-frequencies
- ?
- Image rejection
- 90 dB
- Audio output
- 2W
Transmitter
- TX-range
- 70.2500–70.4875 MHz
- Modulations
- FM
- RF-output
- High: 25 W, Low: 5 W
Connections
- Antenna
- SO-239
- Impedance
- 50Ω
- Other
- -
Electrical
- Power requirements
- 13.8V DC
- Current drain RX
- ?
- TX
- 4 A max
Physical
- Dimensions (w×h×d)
- 185 × 60 × 200 mm (7.28 × 2.36 × 7.87 in)
- Weight
- 825 gr (1.8 lbs)
- Form factor
- Mobile
- Manufactured
- Between 19xx and 20xx in Great Britain
Other features
- Usage
- Amateur / Ham radio operators
- Features + options
- -
- Accessories
- -
- RigReference ID
- 2222
- MPN
- AKD-004001
Manuals, diagrams and brochures
-
No documents available for this particular model.
