General characteristics

HAM bands
?
Frequency stability
?
Tuning steps
?
Memories
20 channels in 2 bank(s)

Receiver

RX-range
118-174 MHz
Modulations
AM   FM
Sensitivity
AM: <1 µV (10 dB S/N)
FM: <0.19 µV (12 dB SINAD)
Selectivity
?
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
?

Transmitter

TX-range
140-150 MHz
Modulations
FM
RF-output
High: 50 W, Low: 10 W

Connections

Antenna
SO-239
Impedance
50 Ω
Other
-

Electrical

Power requirements
13.8V DC
Current drain RX
Max 0.6 A
TX
Max 10 A

Physical

Dimensions (w×h×d)
138 × 51 × 140 mm (5.43 × 2.01 × 5.51 in)
Weight
1.36 kg (3.0 lbs)
Form factor
Mobile
Manufactured
Between 199x and 199x

Other features

Usage
Amateur / Ham radio operators
Features + options
CTCSS encoder
Accessories
-
RigReference ID
2431
MPN
AZDEN-PCS-007000H

Manuals, diagrams and brochures

No documents available for this particular model.

Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Azden PCS-7000H. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the Azden PCS-7000H is around:

  • USD 6.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2004 USD 65.00 Used / Okay drguyor
