Collins HF-380

General characteristics

HAM bands

160m  80m  40m  20m  15m  10m

Frequency stability

?

Tuning steps

1MHz / 1kHz / 100Hz / 10Hz

Memories

?

Receiver

RX-range

10-160 m (0.5-30 MHz continuous)

Modulations

AM   CW   USB   LSB

Sensitivity

1.6-30MHz: 1µV antenna input voltage results in 10dB S/N

Selectivity

?

Filters

?

Receiver system

?

IF-frequencies

?

Image rejection

Greater than 60 dB

Audio output

?

Transmitter

TX-range

0.5-30 MHz

Modulations

CW   USB   LSB

RF-output

100-120W

Connections

Antenna

-

Impedance

50Ω

Other

-

Electrical

Power requirements

Mains

Current drain RX

3 A

TX

20 A

Physical

Dimensions (w×h×d)

394 × 190 × 457 mm (15.51 × 7.48 × 17.99 in)

Weight

27.20 kg (60.0 lbs)

Form factor

Base Station

Manufactured

Between 1979 and 1983 in USA

Other features

Usage

Military communication

Features + options

Noise blanker (optional)
Speech processor (optional)
Keypad (optional)

Accessories

-

RigReference ID

2525

MPN

COLLINS-HF-000380

Manuals, diagrams and brochures

No documents available for this particular model.



Upload relevant documents

Reviews

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Collins HF-380. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic price data, today's estimated value of the Collins HF-380 in Good condition is around:

• EUR 3,800

Price History Chart

These estimates are based on the following prices:
