General characteristics

HAM bands
160m  80m  60m  40m  30m (WARC)  20m  17m (WARC)  15m  12m (WARC)  11m (CB)  10m
Frequency stability
?
Tuning steps
Continuous
Memories
8 channels in 1 bank(s)

Receiver

RX-range
0.3-30 MHz in 9 bands
Modulations
AM   CW   USB   LSB
Sensitivity
< 3 µV (15 dB S/N @ 3 kHz bandwidth)
Selectivity
Continuously variable between 1.3-6 kHz (-6 dB)
Filters
?
Receiver system
Single conversion below 1.5 MHz / Double conversion above 1.5 MHz
IF-frequencies
1st: 1.25-1.45 MHz
2nd: 100 kHz
Image rejection
0.3-1.5 MHz: >50 dB / 1.5-10 MHz: >70 dB / 10-30 MHz: >50 dB
Audio output
2.5 W

Connections

Antenna
SO-239
Impedance
75Ω
Other
-

Electrical

Power requirements
Mains
Current drain RX
85 VA max
TX
-

Physical

Dimensions (w×h×d)
426 × 222 × 381 mm (16.77 × 8.74 × 15.00 in)
Weight
22.00 kg (48.5 lbs)
Form factor
Base Station
Manufactured
Between 1967 and 1973 in Great Britain

Other features

Usage
Amateur / Ham radio operators
Features + options
-
Accessories
-
RigReference ID
2618
MPN
EDDYSTONE-000830/7

Manuals, diagrams and brochures

No documents available for this particular model.

Upload relevant documents

Reviews & stories

Rating Title Submitted
Nice set 10 years ago by magnus

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Eddystone 830/7. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the Eddystone 830/7 is around:

  • EUR 25.00
  • USD 81.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2010 EUR 80.00 Used / Good magnus
2001 USD 1500.00 Used / Mint dxace1
