General characteristics

HAM bands
160m  80m  40m  20m  15m  10m
Frequency stability
?
Tuning steps
?
Memories
?

Transmitter

TX-range
10-160 m
Modulations
AM   CW
RF-output
AM: Max 125 W, CW: Max 140 W

Connections

Antenna
-
Impedance
50/600Ω
Other
-

Electrical

Power requirements
Mains
Current drain RX
-
TX
?

Physical

Dimensions (w×h×d)
526 × 350 × 406 mm (20.71 × 13.78 × 15.98 in)
Weight
45.36 kg (100.1 lbs)
Form factor
Base Station
Manufactured
Between 1955 and 1957 in USA

Other features

Usage
Amateur / Ham radio operators
Features + options
-
Accessories
-
RigReference ID
2907
MPN
HEATHKIT-DX-000100

Manuals, diagrams and brochures

No documents available for this particular model.

Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Heathkit DX-100. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the Heathkit DX-100 is around:

  • USD 95.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2020 USD 100.00 Used / Good Ashy Asher
2020 USD 100.00 Used / Good Ashy Asher
2020 USD 100.00 Used / Good MJL
